Hydraulic Press --- Manual 5~60 Tons
Hydraulic Press --- Manual 5~60 Tons
Regular price
$1,402.00 CAD
Regular price
Sale price
$1,402.00 CAD
Unit price
per
Couldn't load pickup availability
Manual hydraulic pressing machines
Pressing force from 5tons to 60tons
Two-pole (5/12T)or four-pole (15/24/40/60T) full-steel structure
Top wheel to adjust pressing position and limit travel distance
Travel distance 20~30mm
Quick oil discharge and fast pressing
Hydraulic pump pressure <40MPa
Work with 5W-10 or 5W-20 mobil oil
Built-in safety enclosure for safety requirements
Accessories include oil tin, hex wrench, o-rings
One-year limited manufacturer warranty
Pressing force from 5tons to 60tons
Two-pole (5/12T)or four-pole (15/24/40/60T) full-steel structure
Top wheel to adjust pressing position and limit travel distance
Travel distance 20~30mm
Quick oil discharge and fast pressing
Hydraulic pump pressure <40MPa
Work with 5W-10 or 5W-20 mobil oil
Built-in safety enclosure for safety requirements
Accessories include oil tin, hex wrench, o-rings
One-year limited manufacturer warranty
| Model | Max. Force | Piston | Stage | Working Space | Weight |
| LPM-5TB | 5 ton | ϕ45mm |
ϕ60mm |
10x10x13cm | 50lbs |
| LPM-12TB | 12 ton | ϕ70mm | ϕ80mm | 12x12x13cm | 60lbs |
| LPM-15T | 15 ton | ϕ80mm | ϕ100mm | 8x8x13cm | 90lbs |
| LPM-24T | 24 ton | ϕ95mm | ϕ120mm | 9x9x15cm | 100lbs |
| LPM-40TL | 40 ton | ϕ130mm | ϕ150mm | 16x16x20cm | 175lbs |
| LPM-60TL | 60 ton | ϕ150mm | ϕ175mm | 16x16x20cm | 250lbs |
